Intel2025
Intel Arc B570
Intel Arc B-Series
Xe2 BattlemageBMG-G21TSMC N5
Memory10 GB GDDR6
Boost clock2,660 MHz
Board power150W
As an Amazon Associate we earn from qualifying purchases
Release context
Intel Arc B570 at a glance
Intel Arc B570 is a 2025 graphics processor from the Intel Arc B-Series family. Its catalog specifications include the Xe2 Battlemage architecture, 10 GB of GDDR6, a boost clock up to 2,660 MHz, a 150W board power rating.
Compare with Another GPU
Select a graphics card to see a side-by-side comparison with the Intel Arc B570.
Boost Clock
2,660 MHz
VRAM
10 GB
TDP
150W
Memory Bandwidth
380 GB/s
Shading Units
2,304
Memory Bus
160 bit
Performance Specs
Base Clock
1,600 MHzBoost Clock
2,660 MHzShading Units / Stream Processors
2,304Memory Specs
VRAM Size
10 GBMemory Type
GDDR6Memory Bus Width
160 bitMemory Clock
2,375 MHzMemory Bandwidth
380 GB/sArchitecture & Manufacturing
Architecture
Xe2 BattlemageCode Name
BMG-G21Process Node
TSMC N5Interface & Power
Bus Interface
PCIe 4.0 x8TDP (Thermal Design Power)
150WDisplay & Dimensions
Pricing & Info
MSRP
$219Launch Date
January 16, 2025Generation
Intel Arc B-SeriesAPI Support
DirectX
DirectX 12OpenGL
OpenGL 4.6Vulkan
Vulkan 1.3OpenCL
